1 relay; 2 normally open contacts; 2 normally closed contacts 5 A 24 V DC with mechanically linked contacts screw terminals
INPUT
Connection voltage - current 24 V DC (21.6...28 V DC) - 29 mA LED display LED (red)
USAGE CATEGORY
AC-1 5 A (24/110/230 V AC) DC-13 2 A (24 V DC); 0.4 A (110 V DC); 0.2 A (230 V DC) AC-15 4 A (24 V AC); 3 A (110 V AC); 2 A (230 V AC)
GENERAL DATA
Mechanical/electrical lifespan 1,000,000 switching cycles/load-dependent Test insulation voltage 2.5 kV Mounting type snap-on to mounting rail TH35 or G32 (EN 60715) Temperature range -20...+50 °C Dimensions H×W×D 75×22.5×85 mm
OUTPUT
Switching voltage max 250 V AC/DC Switching current per output max 5 A Minimum load current 300 mA Switching power (voltage-dependent) max 1000 VA/50 W Switching frequency max 0.1 Hz (with load) Contact material Ag Ni 10 hv Response/release/bounce time 15/15/2 ms
Connection voltage - current 24 V DC (21.6...28 V DC) - 29 mA LED display LED (red)
USAGE CATEGORY
AC-1 5 A (24/110/230 V AC) DC-13 2 A (24 V DC); 0.4 A (110 V DC); 0.2 A (230 V DC) AC-15 4 A (24 V AC); 3 A (110 V AC); 2 A (230 V AC)
GENERAL DATA
Mechanical/electrical lifespan 1,000,000 switching cycles/load-dependent Test insulation voltage 2.5 kV Mounting type snap-on to mounting rail TH35 or G32 (EN 60715) Temperature range -20...+50 °C Dimensions H×W×D 75×22.5×85 mm
OUTPUT
Switching voltage max 250 V AC/DC Switching current per output max 5 A Minimum load current 300 mA Switching power (voltage-dependent) max 1000 VA/50 W Switching frequency max 0.1 Hz (with load) Contact material Ag Ni 10 hv Response/release/bounce time 15/15/2 ms
| Condition | Used |
| Age rating | No age restriction |
| Model | RM 122/24 |
| Manufacturer | MURR Elektronik |
| Content | 1 piece |
| Weight | 200 g |
| Item ID | 1234584540 |
| Item ID | 1234584540 |
MURR Elektronik
MURR Elektronik RM 122/24 output relay 51300
Item number VN-16057
EAN 4048879027694
Condition Used
Available quantity
${ $store.getters.currentItemVariation.stock.net }
EUR 17.45
*
Content
1 piece
immediately available
