Control cabinet socket, for mounting on DIN rail and in service interface, housing color: green, with screw connection, with indicator light, country variant: D, housing width 45 mm
Item from plant decommissioning
Item from plant decommissioning
Dimensions
Width approx. 45 mm Height approx. 75 mm Depth approx. 65.2 mm
Environmental conditions
Ambient temperature (operation) -20 °C ..60 °C Ambient temperature (storage/transport) -20 °C ..60 °C
General
Rated voltage UN 250 V AC Rated current IN 16 A Status indicator Neon lamp or LED with resistor Contact material CuZn37 Typically usable in country D Color green Insulating material PA Standards/Regulations IEC 83 DIN 49440-1
Connection data
Conductor cross-section rigid min 0.2 mm² Conductor cross-section rigid max 4 mm² Conductor cross-section flexible min. 0.2 mm² Conductor cross-section flexible max. 2.5 mm² Conductor cross-section AWG min 24 Conductor cross-section AWG max 12 Connection type Screw connection Stripping length 8 mm Screw thread M3
Width approx. 45 mm Height approx. 75 mm Depth approx. 65.2 mm
Environmental conditions
Ambient temperature (operation) -20 °C ..60 °C Ambient temperature (storage/transport) -20 °C ..60 °C
General
Rated voltage UN 250 V AC Rated current IN 16 A Status indicator Neon lamp or LED with resistor Contact material CuZn37 Typically usable in country D Color green Insulating material PA Standards/Regulations IEC 83 DIN 49440-1
Connection data
Conductor cross-section rigid min 0.2 mm² Conductor cross-section rigid max 4 mm² Conductor cross-section flexible min. 0.2 mm² Conductor cross-section flexible max. 2.5 mm² Conductor cross-section AWG min 24 Conductor cross-section AWG max 12 Connection type Screw connection Stripping length 8 mm Screw thread M3
| Condition | Used |
| Age rating | No age restriction |
| Model | SD-D/SC/LA |
| Manufacturer | Phoenix Contact |
| Content | 1 piece |
| Weight | 100 g |
| Item ID | 1234577491 |
| Item ID | 1234577491 |
Phoenix Contact
Phoenix Contact SD-D/SC/LA 2964898 Socket Control Cabinet Socket 230V 16A
Item number 2964898
EAN 4017918190651
Condition Used
Available quantity
${ $store.getters.currentItemVariation.stock.net }
EUR 5.45
*
Content
1 piece
immediately available
